External GPS Antenna for Actis 7 wifi

External GPS Antenna for SatNav Actis 7 wifi

Price: 30.00 EUR

Price (VAT incl.): 36.00 EUR


navigation Actis 7 WiFi Truck

Professional GPS Navigation device ACTIS 7 with preinstalled navigation software Pocket Navigator is a modern navigation which also offers applications for spare time: audio and video player, photo viewer, calculator and notepad.

At the same time, it can be connected to the Internet thanks to integrated WiFi antenna and used for searching relevant information, accessing to e-mail address, having fun etc.

Actis 7 WIFI also means:

  • Big 7 inch hi-resolution display
  • Dual core processor
  • WiFi
  • Support for an external TMC receiver (traffic information)
  • Possibility to connect it with a rear camera
  • Audio/Video input and output
  • Multitasking for using more applications simultaneously
  • USB host port for connection with another devices
  • The integration into more sophisticated logistics systems can be realized by one connector which includes a power supply and 2 serial ports.

Actis 7 also supports remote TCP/IP messaging through our vehicle tracking unit VTU 10. You can send text messages, assign new destinations from your dispatching central, etc.

Moreover you can simply manage the work status of your truck, that includes:

  • Driver´s name
  • Refueling
  • Time to the destination
  • Delivery status

Your Application in Actis 7

You can run your application for WinCE 6.0 under the button CUSTOMER

WinCE 6.0 in Actis7 contains .NET 3.Your Application can run with Navigator simultaneously. You can switch between the Applications with the Hardware buttons or with TCP/IP commands

Integration into superiour telematic systems

Navigator can be integrated with other programs with a number of external commands. These can be sent to Navigator via serial interface or TCP / IP. So you can resize the Navigator window, change various settings, send new routing points or communicate with the driver similar to ICQ and many others. You can also obtain information from Navigator, e.g. remaining time or distance to destination, current coordinates, and many others.

The list of current commands can be found here.

Other modifications in Navigator can be done by changing the configuration files. Buttons may be removed from the menu or may be added to the map/navigation screen.


Basic features

  • Modification of roads parameters
  • Detailed road types set preferences for searching of optimal routes
  • Warnig for speeding
  • Airplane mode (off-road)
  • Extended TCP/IP commands for remote communication or communication between 2 softwares (dispatcher can chat with conductor or can send him new destination, etc. using our VehicleTruckUnit)
  • Route optimization for large vehicles based on vehicle height and weight. Avoid low bridges and narrow lanes.

Voice guidance

  • Intuitive voice navigation in different languages
  • Door to door route planning
  • Cross-border routing without the need to switch between countries or to a less detailed map
  • Overview of the upcoming manoeuvre and its distance
  • ETA to your destination

GPS satellite navigation

  • Assistant for traffic lines shifting
  • 2D/3D mode allows realistic visual map display
  • Day/night modes switch colour schemes for day or night time driving
  • Map rotates in driving direction, or north up


  • Find nearest points of interest
  • Postcodes
  • Full GB postcodes (1.8 million)

Speed cameras

  • Hear audible warnings as you approach speed cameras

Special features

  • Odometer keeps a track of private and business mileage
  • Routing modes for car, pedestrian, truck
  • Traffic restrictions for Trucks
  • Optimization of the order of waypoints
  • Add your own favourites
  • Direct import of your own favourites databases from xls, dbf, Access, ArcInfo, MapfInfo files or another ODBC sources
  • Route avoidance - block off certain road from your route
  • Multitasking for using more applications simultaneously
  • Real 3D icons of important landmarks

Tech. specifications

Physical Attributes

Dimensions in millimetres: 182 x 115 x 21 (width x height x depth)
Weight: 410g

Processor and Memory

CPU: Telechips TCC8803 Dual Core 1,12GHz core + 1GHz dsp
ROM size: 256MB NAND Flash
RAM size: 512MB DDR2
OS: MS Windows CE.NET 6.0 core

Graphical subsystem

Display: Digital TFT Touch screen LCD
Colordepth: 24 bit full color
Resolution: 800 x 480 WVGA
Diagonal: 7 inches
Brightness 400 cd/m

Audio subsystem

Speaker: 1,5 W (built-in) 36 π (Stereo) x 2
Audio Output: 3.5mm, stereo


Positioning Device: C Touchscreen
Expansion Slots: MMC, SD
USB Connector: USB 2.0 host
IR receiver IR remote control
GPS Module: UBLOX 7
Serial Port: RS 232, TTL

Power Supply

Power: 12V/14V 1.5 A (side 1port, bottom 1port)
Battery: 1600mAH Li-polymer


Video player: Codec format : MPEG-1/2/4, H.263, H.264
File format :3GP, MP4, AVI, MKV, MPG, M2TS, TS/TP, FLV
Audio player: Codec format : MP2, MP3, MIDI, OGG, AAC, WAV, FLAC, BSAC, DTS
File format : Ogg Media (*.ogg) / MP3 (*.mp3) / WAV
Photo viewer JPG, JPEG, PNG, BMP,GIF
[Note]: Because of codec licensing some files may not play.


TMC: Supports external TMC receiver
AV in: for external source
AV out: Dual display (optional)
Rear Camera: Input for Rear camera
WiFi: 802.11/b/g/n

Map coverage

Map coverage.

To check availability of other states please contact us.
